Hanwha Vision QNE-C9013RL
MSRP$750.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Hanwha Vision QNE-C9013RL
- Network surveillance camera
- dome
- color (Day&Night)
- 8 MP
- 3840 x 2160
- M12 mount
- fixed iris
- fixed focal
- LAN 10/100
- MJPEG, H.264, H.265
- PoE Class 3
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $750.00 |
| Mfr Part #: | QNE-C9013RL |
| SHI Part #: | 47875354 |
| Category: | Cameras |
| UNSPSC: | 45121500 |
| Manufacturer: | HANWHA VISION |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Cameras |
| Description | Hanwha Vision QNE-C9013RL - Network surveillance camera - dome - color (Day&Night) - 8 MP - 3840 x 2160 - M12 mount - fixed iris - fixed focal - LAN 10/100 - MJPEG, H.264, H.265 - PoE Class 3 |
| Manufacturer | HANWHA VISION |
| MSRP | $750.00 |
| UNSPSC | 45121500 |
| Main Specifications | |
| Dimensions & Weight / Depth | 14 cm |
| Dimensions & Weight / Height | 9.96 cm |
| Dimensions & Weight / Weight | 790 g |
| Dimensions & Weight / Width | 14 cm |
| Header / Brand | Hanwha Vision |
| Miscellaneous / Product Color | White |
| Packaged Quantity | 1 |
| Camera | |
| Digital Video Capture Resolution | 1024 x 768, 1280 x 1024, 1280 x 720, 1280 x 960, 1600 x 1200, 1920 x 1080, 2048 x 1536, 2560 x 1440, 2592 x 1944, 2688 x 1520, 3072 x 1728, 3840 x 2160, 640 x 360, 640 x 480, 720 x 480, 720 x 576, 800 x 448, 800 x 600 |
| Digital Video Format | MJPEG, H.264, H.265 |
| Exposure Range | 1/5 sec - 1/12000 sec |
| Features | Auto ICR, Backlight Compensation (BLC), Wide Dynamic Range (WDR), Samsung Super Dynamic Range (SSDR), Samsung Super Noise Reduction (SSNR) V, Digital Image Stabilization (DIS), built-in strobe light, image masking, Gain Control, Automatic Tracing White (ATW), Automatic White Balance Control (AWC), Lens Distortion Compensation (LDC), auto flicker correction, image flip, image mirror, Hallway View, Object Detection, object classification, Person Detection, vehicle type classification, Virtual Line detection, appearing / disappearing detection, loitering detection, intrusion detection, entrance / exit detection, Defocus Detection, IP address filtering, user access log, 802.1x authentication, queue management, Heat Map, network disconnection trigger, alarm function, notification picture to FTP, notification picture to E-mail, NAS alerts, Handover, strobe light alarm, WiseStream III support, WiseNR II, Variable Bitrate (VBR), Constant Bitrate (CBR), Multicast Streaming, Unicast Streaming, digest authentication, ONVIF (Profile S) support, ONVIF (Profile G) support, ONVIF (Profile T) support, ONVIF (Profile M) support, brute force delay protection |
| Flash Memory | 1 GB |
| Frame Rate (max) | 30 frames per second |
| Infrared Distance | 30 m |
| Infrared LEDs | Yes |
| Max Digital Video Resolution | 3840 x 2160 |
| Minimum Illumination |
|
| Motion Detection | Yes |
| RAM | 2 GB |
| Type | Color - Day&Night - fixed |
| Environmental Parameters | |
| Max Operating Temperature | 60 °C |
| Min Operating Temperature | -40 °C |
| Relative Humidity (operating) | 0 - 95% RH |
| Expansion / Connectivity | |
| Ports | LAN/power - RJ-45 |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| General | |
| Connectivity Technology | Wired |
| Depth | 14 cm |
| Device Type | Network surveillance camera |
| Form Factor | Dome |
| Height | 9.96 cm |
| Weight | 790 g |
| Width | 14 cm |
| Image Sensor | |
| Type | 8 MP CMOS 1/2.8" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP, UDP, RTCP, RTSP, NTP, HTTP, HTTPS, SSL, TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMP 1, SNMP 2c, SNMP 3, ARP, DNS, DDNS, QOS, UPnP, LLDP, SRTP, MQTT, Bonjour, EAP |
| Lens Construction | |
| Diagonal Field of View (degree) | 127 |
| Focal Length | 3 mm |
| Horizontal Field of View (degree) | 108 |
| Lens Iris | F/1.6 fixed iris |
| Min Focus Distance | 0.5 m |
| Type | M12 mount - fixed focal |
| Vertical Field of View (degree) | 59 |
| Miscellaneous | |
| Color | White, RAL 9003 |
| Compliant Standards | IEC/EN 60529 IP66, IEC/EN 60529 IP67, IEC/EN 62262 IK10, IEEE 802.3af Class 3, FCC 47 CFR Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), UKCA, EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, VCCI-CISPR 32 Class A, AS/NZS CISPR 32 Class A, UL 62368-1, CAN/CSA-C22.2 No. 62368-1, IEC/EN 62471, IEC/EN 63000, EN 62676-4, NDAA |
| Panning | |
| Range (degree) | 0 to 350 |
| Power | |
| Power Requirements | PoE Class 3 |
| Tilting | |
| Range (degree) | 0 to 75 |
