Eaton 9PX 9PX1500GRT
MSRP$4,353.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Eaton 9PX 9PX1500GRT
- UPS (rack-mountable / external)
- AC 200/208/220/230/240/250 V
- 1350 Watt
- 1500 VA
- RS-232, USB
- output connectors: 8
- 2U
- black, silver
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $4,353.00 |
| Mfr Part #: | 9PX1500GRT-L |
| SHI Part #: | 41800105 |
| Category: | Uninterruptible power supplies |
| UNSPSC: | 39121011 |
| Manufacturer: | Eaton |
| Product Type: | Hardware |
Network Interface Cards
- Remote management adapter
- Gigabit Ethernet x 1
- for P/N: 9PX1500GRT-L, 9PX1500RT-L, 9PX2000RT-L, 9PX2200GRT-L, 9PX3000GRT-L, 9PX3000RT-L
MSRP $473.00
$406.00
- Remote management adapter
- RS-232
- for P/N: 5PX1500RTNG2, 5PX2000RTNG2, 5PX3000HRTG2, 5PX3000RT3UNG2, 5PX3000RTG2, 9PX6K-L
MSRP $160.00
$145.00
Power Management
| General Information | |
|---|---|
| Category | Uninterruptible power supplies |
| Description | Eaton 9PX 9PX1500GRT - UPS (rack-mountable / external) - AC 200/208/220/230/240/250 V - 1350 Watt - 1500 VA - RS-232, USB - output connectors: 8 - 2U - black, silver |
| Manufacturer | Eaton |
| MSRP | $4,353.00 |
| UNSPSC | 39121011 |
| Main Specifications | |
| Dimensions & Weight / Depth | 45 cm |
| Dimensions & Weight / Height | 8.64 cm |
| Dimensions & Weight / Width | 43.9 cm |
| General / Subcategory | UPS |
| Header / Brand | Eaton |
| Miscellaneous / Product Color |
|
| Networking / Remote Management Interface |
|
| Packaged Quantity | 1 |
| Power Device / Form Factor | Rack-mountable / external |
| Power Device / Output Connector Qty | 8 |
| Power Device / Power Capacity (VA) | 1500 VA |
| Power Device / UPS Technology | On-line |
| Power Device / Voltage Required | AC 200/208/220/230/240/250 V |
| Product Type | UPS |
| Service & Support / Type | 2-year warranty |
| Battery | |
| Technology | Lithium ion |
| Transfer Time | 0 ms |
| Type | Expandable |
| Compatibility Information | |
| Designed For | P/N: 9PXEBM48RT-L |
| Dimensions & Weight | |
| Depth | 45 cm |
| Height | 8.64 cm |
| Width | 43.9 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 96% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Sound Emission | 40 dB |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x Mini Slot |
| Interfaces |
|
| General | |
| Color | Black, silver |
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included |
|
| Compliant Standards | IEC 62040-2 class B, CISPR 22 Class B, FCC Part 15 B, VCCI Class B, cULus, RoHS |
| Features | Rotatable LCD panel, Advance Battery Management (ABM), hot-swappable batteries, internal bypass, cold-start function, LED indicators, double conversion |
| Included Accessories | Tower stand, 4-post rail kit |
| Rack Mounting Kit | Included |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Power Device | |
| Efficiency | 91.2% |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x power IEC 60320 C14 |
| Input Voltage | AC 200/208/220/230/240/250 V |
| Input Voltage Range | AC 100 - 276 V |
| Max Spike Voltage | 510 V |
| Output Voltage | AC 200/208/220/230/240 V ± 2% |
| Output Waveform | Sinewave |
| Power Capacity | 1350 Watt / 1500 VA |
| Power Factor (PF) | 0.99 |
| Power Output Connectors Details | 8 x power IEC 60320 C13 |
| Surge Energy Rating | 296 Joules |
| Surge Suppression | Yes |
| Total Harmonic Distortion (THD) | 5 % |
| UPS Technology | On-line |
| Software / System Requirements | |
| Software Included | Intelligent Power Software Suite |
| Sustainability Information | |
| ENERGY STAR | Yes |
