Hardware Computer Components Motherboards
Add to My Favorites
Motherboards

MSI MAG Z790 Tomahawk WIFI

MSRP$229.99
$222.45
MSI MAG Z790 Tomahawk WIFI
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • Motherboard
  • ATX
  • LGA1700 Socket
  • Z790 Chipset
  • USB-C Gen 2x2, USB 3.2 Gen 2, USB 3.2 Gen 1, USB-C Gen2
Contracts
   DIR-CPO-5094
MSI MAG Z790 Tomahawk WIFI
  • Motherboard
  • ATX
  • LGA1700 Socket
  • Z790 Chipset
  • USB-C Gen 2x2, USB 3.2 Gen 2, USB 3.2 Gen 1, USB-C Gen2
  • 2.5 Gigabit LAN, Wi-Fi 6, Bluetooth
  • onboard graphics (CPU required)
  • HD Audio (8-channel)
  Additional Details
Price: $222.45
MSRP: $229.99
Mfr Part #: Z790TOMWI
SHI Part #: 45464732
Category: motherboards or daughterboards
UNSPSC: 43201513
Manufacturer: MSI
Product Type: Hardware
General Information
Categorymotherboards or daughterboards
DescriptionMSI MAG Z790 Tomahawk WIFI - Motherboard - ATX - LGA1700 Socket - Z790 Chipset - USB-C Gen 2x2, USB 3.2 Gen 2, USB 3.2 Gen 1, USB-C Gen2 - 2.5 Gigabit LAN, Wi-Fi 6, Bluetooth - onboard graphics (CPU required) - HD Audio (8-channel)
ManufacturerMSI
MSRP$229.99
UNSPSC43201513
Main Specifications
Dimensions & Weight / Depth24.384 cm
Dimensions & Weight / Width30.48 cm
Header / BrandMSI
Mainboard / Chipset TypeIntel Z790
Mainboard / Processor SocketLGA1700 Socket
Networking / Data Link Protocol
  • 2.5 Gigabit Ethernet
  • Bluetooth 5.3
  • IEEE 802.11a
  • IEEE 802.11ac
  • IEEE 802.11ax (Wi-Fi 6E)
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n
Packaged Quantity1
Video Output / TypeGraphics adapter (CPU required)
Audio
Audio CodecRealtek ALC4080
Compliant StandardsHigh Definition Audio
TypeHD Audio (8-channel)
Expansion / Connectivity
Expansion Slots
  • 1 x CPU
  • 4 x DIMM 288-pin
  • 1 x PCIe 5.0 x16
  • 1 x PCIe 4.0 x16 (x4 mode)
  • 1 x PCIe 3.0 x1
  • 2 x M.2 socket (2242/2260/2280 M.2 Key M slot)
  • 1 x M.2 socket (2260/2280/22110 M.2 Key M slot)
  • 1 x M.2 socket (2260/2280 M.2 Key M slot)
  • 1 x M.2 socket (Key E)
Interfaces
  • 1 x HDMI
  • 1 x DisplayPort
  • 4 x USB 3.2 Gen 1
  • 4 x USB 3.2 Gen 2
  • 1 x USB-C 3.2 Gen 2
  • 1 x USB-C 3.2 Gen2x2
  • 1 x audio line-out - mini-jack
  • 1 x microphone - mini-jack
  • 1 x audio line-out (center/subwoofer) - mini-jack
  • 1 x audio line-out (rear) - mini-jack
  • 1 x audio line-in - mini-jack
  • 1 x SPDIF out
  • 2 x antenna
  • 1 x LAN (2.5Gigabit Ethernet)
Internal Interfaces
  • 4 x USB 2.0 - header
  • 2 x USB 3.2 Gen 1 - header
  • 1 x USB-C 3.2 Gen 2 - header
  • 1 x audio - header
  • 1 x Thunderbolt - header
  • 1 x SPI - header
Power Connectors24-pin main power connector, 2 x 8-pin ATX12V connectors
Storage Interfaces
  • SATA-600 -connectors: 7 x 7pin SATA - RAID 0 / RAID 1 / RAID 10 / RAID 5
  • PCIe 4.0 -connectors: 3 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5
  • SATA-600 / PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5
Features
BIOS FeaturesMSI ClickBIOS 5
Hardware FeaturesDebug LED, Water Pump Header, Clear CMOS Button, flash BIOS button, MSI Audio Boost 5, MSI Core Boost, M.2 Shield FROZR, MSI Memory Boost, 90A Smart Power Stage, 6 Layer PCB, 2oz Copper PCB, Extended Heatsink Design, MSI Mystic Light, MSI Steel Armor, DIY Friendly Design, Surface Mount Technology (SMT), 16+1+1 Phase Power Design
General
Chipset TypeIntel Z790
Compatible Processors(supports 12th and 13th Generation Intel Core / Pentium Gold / Celeron)
Max Processors Qty1
Processor SocketLGA1700 Socket
Product TypeMotherboard - ATX
LAN
Network Interfaces2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.3
Miscellaneous
Cables Included2 x Serial ATA cable
Compliant StandardsFISMA, FIPS, FCC Part 15 Class B, WEEE, JIS C 0950, DisplayPort 1.4
Depth24.384 cm
Included AccessoriesUSB drive, EZ M.2 clips, cable stickers, Wi-Fi antenna
Software IncludedMSI Center, AIDA64 Extreme (60 days trial)
Width30.48 cm
Supported RAM
Bus Clock4800 MHz, 5000 MHz, 5200 MHz, 5400 MHz, 5600 MHz, 5800 MHz (O.C.), 6000 MHz (O.C.), 6200 MHz (O.C.), 6400 MHz (O.C.), 6600 MHz (O.C.), 6800 MHz (O.C.), 7000 MHz (O.C.), 7200 MHz (O.C.)
FeaturesIntel Extreme Memory Profiles (XMP) 3.0, dual channel memory architecture
Max Size128 GB
Registered or BufferedUnbuffered
Supported RAM Integrity CheckNon-ECC
TechnologyDDR5
